IEEE Approves 802.1AS-2020 Timing & Synchronization Standard for TSN Applications

By August 12, 2020 October 9th, 2020 No Comments

The prospect of a standard, real-time industrial Ethernet that overcomes the drawbacks of numerous non-interoperable industrial Ethernet implementations has reached a significant milestone.  On June 19th, the IEEE (Institute of Electrical and Electronics Engineers) published the 802.1AS-2020 standard for Timing & Synchronization of TSN networks.  TSN and the associated joint IEC/IEEE 60802 TSN Profile for Industrial Automation offer the prospect for delivering standard, unmodified real-time industrial Ethernet (IE) that meets the requirements for industrial automation while overcoming legacy drawbacks in areas such as latency, fault tolerance, scalability, and determinism.

Fulfilling the Need for a Standard Real-Time Ethernet

This important component of the Ethernet TSN standard was deemed necessary since current IEEE 802 technologies for time-sensitive applications, such as high-quality audio/video streaming or industrial control, do not assure that the applications can present data with acceptable jitter, wander, and time deviation.  Prior solutions, such as IEEE 1588-2002, operate at layer 3 and can represent significant cost and complexity.

The new IEEE 802.1AS-2020 standard is designed to operate at layers 1 and 2, making it easier for networked devices to meet these requirements  across a variety of time-sensitive applications, including multiple data streams delivered to multiple endpoints.  Availability of the standard scheduling component will help alleviate the potential for differing physical layer implementations across vendor offerings.

The standard encompasses maintenance of synchronized time during normal operation as well as addition, removal, or failure of network components and/or reconfiguration.  The published standard also now specifies the synchronization of managed objects as part of hot standby as well as protocols and procedures to ensure timing requirements are met in audio, video, control, and other time-sensitive network activities.

Part of a Larger Real-Time Ethernet Implementation

Time synchronization profiles are just one of the components needed at each network element where time-sensitive application data is mapped/demapped or a time-sensitive function is performed.  This is reflected in the numerous other standards that make up the overall TSN standard.  For example, the new standard specifies use of the existing IEEE 1588 Precision Time Protocol (PTP) standard where applicable in context of the already-ratified IEEE 802.1Q (VLANs).

Availability of standard industrial network technology managed as part of the overall IEEE 802.1 Ethernet development work promises numerous advantages to industrial customers.  These include standard, less expensive, and more widely available silicon, multi-vendor support, lower costs, and eliminating the need for vendor or network-specific real-time implementations.  Scheduling and other components of TSN can still be complex to implement, however, and require use of managed switches.

TSN’s focus on layers 1 and 2 does not address continued use of competing industrial application layers in Ethernet-based automation architectures.  Industry efforts are under way to address application layer interoperability, but these activities are taking place outside of IEEE.  Examples include the interoperability efforts of the AVNU Alliance and the TSN Testbed activity within the Industrial Internet Consortium, as well as the push to make OPC UA over TSN the universal means for communicating between industrial controllers and the cloud.

Reprinted with permission from Arc Advisory Group, where Chantal Polsonetti is Vice President, Advisory Services. This blog is part of ARC’s continuing coverage of the industrial automation network infrastructure market and the industrial IoT edge.  Further information on ARC’s coverage can be found on the firm’s dedicated Industrial IoT edge webpage.
